LED Color Shift: Examining a Phosphor Malfunction in White LEDs

Household illumination has significantly evolved, with white LED bulbs becoming the preferred choice. This shift is primarily attributed to their energy efficiency and robustness. Yet, when the light intensity is increased, these bulbs tend to generate high temperatures, correlating with...

,   and  Administrator
3 min read
LED lights, predominantly white in hue, have become widespread in homes, primarily due to their...
LED lights, predominantly white in hue, have become widespread in homes, primarily due to their energy-efficient nature and strong dependability. Increasing their brightness, however, can lead to higher temperatures and potential correlations.

LED Color Shift: Examining a Phosphor Malfunction in White LEDs

Revised Article:

White LED bulbs are all the rage in homes these days, thanks to their power efficiency and dependability. But crank up the light output, and you'll start seeing high temperatures and some intriguing failure modes. Check out the video on YouTube from the [electronupdate] channel, where they demonstrate a Philips MR16 LED spot that was putting out a distinctive purple light.

Prying off the front cover, the culprit seemed to be one of the four LEDs losing its phosphor coating, exposing the 405 nm LED underneath. You see, white LEDs are usually UV or 405 nm (blue) LEDs with a phosphor coating that transforms the emitted wavelength into a broad spectrum of visible light, or a specific wavelength to give off white light. This failure mode is as evident as daylight.

Examining the PCB under a microscope reveals that the crumbled phosphor wasn't just an isolated case with this package. The other three packages showed clear cracks in their phosphor coating. It's unclear whether it's the heat in these high-intensity spot lamps or just age, but one thing is sure— over time, these white LED packages tend to lose their phosphor coating, leaving behind just the LED stripped of its color convertor. Ideally, one could patch it up with some fresh phosphor, but a more practical solution seems to be replacing these LED packages every few years.

Props to [ludek111] for the tip.

The Nitty-Gritty

When it comes to white LED bulbs, various issues can crop up, particularly under high output and prolonged use. Recognizing these problems and how to address them is vital for ensuring longevity and optimal performance.

Phosphor Degradation and Flaking

White LEDs largely consist of a blue or ultraviolet LED die covered with a phosphor layer that converts the emitted light into white. Over time, under high heat and intense operation, the phosphor can crack, flake, or peel off, revealing the underlying emitter, resulting in a color shift—often purplish if the underlying LED emits around 405 nm—as the phosphor is now gone, leaving the light unconverted. This failure is worsened by inadequate heat management.

Operating at excessive drive current or with insufficient heat dissipation leads to increased temperatures within the LED package. This can cause the phosphor to break down more rapidly, the encapsulating material to yellow or crack, and the LED die itself to suffer reduced efficiency or catastrophic failure via burnout or fragmentation. Heat also accelerates other chemical and physical degradation mechanisms.

Electrical Overstress

Driving LEDs above their rated current or voltage can cause immediate or gradual failure. Overdriving results in excessive heat and may cause color shifts, reduced output, or complete burnout. Electrical transients or surges can also damage the semiconductor structure or bond wires.

Encapsulant Degradation

The material surrounding the LED (often silicone or epoxy) can yellow, crack, or become opaque due to heat and UV exposure. This leads to reduced light output, beam distortion, and, ultimately, failure due to exposure and damage to the underlying components.

The Solutions

Enhanced Thermal Management

  • Heat Sinks: Utilize efficient heat sinks and thermal interface materials to eliminate heat away from the LED package.
  • Current Limitation: Stay clear of overdriving the LED. Use LED drivers with current limits and thermal protection features.
  • Considerate Design: Ensure adequate spacing between LEDs and good airflow, especially in high-intensity or enclosed fixtures.

Controlling Drive Current and Voltage

  • Accurate Drivers: Use constant-current LED drivers with feedback or EEPROM-based settings for current regulation.
  • Avoid Overvoltage: Protect against voltage spikes and surges with suitable circuitry.

Protecting the Phosphor and Encapsulant

  • High-Quality Materials: Use high-quality phosphor coatings and sturdy encapsulants designed for high temperatures and UV exposure.
  • Regular Inspection: Frequently inspect high-intensity LED fixtures for signs of discoloration or output changes, which may indicate early phosphor or encapsulant failure.

Replacing Ageing Components

  • Lifespan Awareness: Acknowledge that even with good practices, phosphor and encapsulant degradation are inevitable over extended periods. Plan for periodic replacement of LED packages before complete failure.
  • Maintenance Schedule: Replace LED packages or entire fixtures as part of regular maintenance, especially in critical or high-utilization applications.
  1. It's apparent that the failure mode in white LED bulbs, such as the one demonstrated in the electronupdate video, is often due to the degradation of the phosphor coating, a crucial component in the science of white LEDs that involves technology.
  2. In the nitty-gritty of white LED bulbs, one common problem is phosphor degradation, which can include cracking, flaking, or peeling off. This failure mode, particularly under high heat and intense operation, can result in a color shift and eventual loss of the phosphor coating, a clear indication of the influence of science and technology in these lighting solutions.
